60hz electric start diesel generator
| MOQ | 5 – 10 Pieces | 10 – 100 Pieces | > = 100 Pieces |
| Discount | 95% | 90% | 80% |
60Hz electric start diesel generator, crafted by MATCHUP, a trusted manufacturer known for delivering high-quality and reliable power solutions.
specification
| rated frequency [hz] | 50/60 |
| rated voltage [v] | 220, 230, 240, 110/220, 115/230, 120/240, 220/380, 230/400, 240/415 |
| rated output power [kva] | 6.5(8.1) 6.8（8.5） |
| max output power [kva] | 7.0(8.8) 7.3（9.1） |
| dc output | 12v 8.3a |
| phase number | single phase / three phase |
| excitation mode | self-excitation, brush |
| power factor φ | 1.0(0.8) |
| insulation grade | f |
| motor specifications | 204*140 |
| battery specifications | 36ah |
| fuel tank capacity [l] | 24.0 |
| engine model | hp195fe |
| starting system | electric starting |
| engine type | 1-cylinder ,4-stroke, air-cooled,veritical |
| broke * stroke [mm] | 95*75 |
| displacement | 0.532 |
| compression ratio | 20 |
| rated rotation speed [rpm] | 3000 3600 |
| rated power [kw] | 8.0 9.2 |
| fuel type | 0#(summer), -10#(winter), diesel oil |
| lube | sae10w30 ( above cd grade ) sae10w30 |
| low oil pressure alarm system | with |
| optional standard | ats、remote control、 heater/emergency stop button/pressure reducing valve cable、digital smart panel |
description
Our 60Hz electric start diesel generator is built with heavy-duty materials and expert craftsmanship. Whether you need power at home or on the job site, our generator delivers.
This electric start diesel generator is designed to provide reliable power with a frequency of 60 hertz, which is standard in many countries.
The electric start feature allows for easy and convenient starting of the generator with the push of a button, eliminating the need for manual cranking.
Moreover, their advanced technology ensures less noise and lower emissions, contributing to a better working environment and compliance with environmental regulations.
detail
engineered excellence: air-cooled generators manufacturers
Why dealers trust MATCHUP as a partner
Need a generator? Look no further! MATCHUP is a generator manufacturer that builds reliable generators right in our own factory.
We offer expert advice to help you choose the right generator, and our outstanding service ensures your peace of mind.
Additionally, MATCHUP offers comprehensive training and technical support, ensuring dealers are well-equipped to service and support their customers.
Flexible and customizable options provided by MATCHUP enable you to offer tailored solutions to their clients, increasing customer satisfaction and loyalty.
So, ditch the pull cord and experience the easy electric start and reliable power of a MATCHUP generator. Contact us today!
power your world:
choose 60hz electric start diesel generator
looking for more information?
simplified maintenance
The silent air-cooled generators eliminate the need for water pumps, radiators, coolant hoses, and potential leak or freeze issues. This means easier maintenance and less downtime.
flexible applications
efficient design
MATCHUP air-cooled diesel generators are designed for efficiency, resulting in excellent fuel economy and lower operating costs compared to liquid-cooled models.
matched reliability
