high pressure irrigation pump
| MOQ | 5 – 10 Pieces | 10 – 100 Pieces | > = 100 Pieces |
| Discount | 95% | 90% | 80% |
MATCHUP is a professional high pressure irrigation pump manufacturer, supplying MC15H pumps with 65 m lift for agricultural and industrial use.
specification
| Specification | MC15H |
| Inlet and outlet size (MM) |
40 (1.5”)
|
| Pump lift (M) | 65 |
| Suction height (M) | 7 |
| Flux (M³/H) | 16 |
| Impeller | Single |
| Model | MC168F-1 |
| Type |
Single Cylinder, Air-cooled, 4-stroke
|
| Displacement (CC) | 196 |
| Max power (KW) | 4.7 |
| Rated power (KW) | 4.2 |
| Rated speed (RPM) | 3600 |
| Bore × stroke (MM) | 68*54 |
| Compression ratio | 8.5 |
| Ignition system | T.C.I |
| Fuel tank volume (L) | 3.6 |
| Mass weight (KG) | 26 |
| Size (L×W×H) (MM) |
510*385*425
|
| 20GP (Set) | 330 |
| 40HQ (Set) | 828 |
key features and benefits
The MC15H is a petrol-engine high pressure pump is capable of efficiently delivering water over long distances at high pressure, making it ideal for large-scale agricultural irrigation, sprinkler systems, landscaping and industrial water delivery.
High pressure, long reach: 65 m pump lift and 16 m³/h flow push water to far-end sprinklers and higher ground, so one pump can cover more land. Helps optimize crop irrigation while minimizing water waste, making it an essential solution for modern irrigation needs.
Draws from below: a 7 m suction height lets the pump pull water from ponds, canals, wells and tanks below pump level.
Designed for durability, the MC15H uses high-grade corrosion-resistant materials such as stainless steel and heavy-duty aluminum components to ensure long-term reliability and very low maintenance costs.
Boost your business with superior water pump manufacturer
water pump manufacturers
Add the MC15H high pressure irrigation pump to your range. MATCHUP always uses high-quality materials and advanced manufacturing techniques to produce pumps that meet strict industry standards. We offer factory-direct, with support from first sample to final delivery.
Contact us today to learn more about becoming a MATCHUP dealer and providing your customers with this excellent product.
offer your customers:
innovative high pressure irrigation pump solutions
looking for more information?
customization and flexibility
MATCHUP is flexible and customizable, so we can produce exactly what you need. Whether you’re looking for a specific configuration or level of performance, our dedicated engineering team will work closely with you to develop a water pump solution that perfectly matches your operational needs and objectives.
sustainability
manufacturing ability
MATCHUP’s use of the latest automated production technology and stringent quality control processes allows us to maintain excellent productivity and consistently deliver on schedule, thus ensuring our excellent reputation as a manufacturer of water pump.
competitive pricing
